Documentation

This guide shows how to integrate Authsignal with Next.js and Supabase in order to add an MFA step after sign-in.

The user flow is as follows:

The user enters their email and password to sign in
If the user has set up MFA, they're prompted to complete an MFA challenge (via Authenticator App) in order to complete sign-in
If the user has not set up MFA, they're signed in immediately and will see a button to set up MFA

The approach uses a temporary encrypted cookie to ensure that the Supabase auth cookies (access_token and refresh_token) are only set if the MFA challenge was successful. Session data is encrypted using @hapi/iron.

The full code version of this example can be found here.

A live demo can be found here.

How it works

A sign-in form posts email and password to the Next.js API route /api/sign-in
The signIn API route calls the Supabase client's signInWithEmail method and gets back a session object
The signIn API route then calls the Authsignal client's track method to determine if an MFA challenge is required
If a challenge is required, the signIn API route saves the session object in a temporary encrypted cookie and redirects to Authsignal
Once the challenge is completed, Authsignal redirects back to /api/callback which retrieves the session and sets the Supabase auth cookies
The callback API route then redirects to the index page which is protected with Supabase's withPageAuth wrapper around getServerSideProps

Step 1: Configuring an Authsignal tenant

Go to the Authsignal Portal and create a new project and tenant.

You will also need to enable at least one authenticator for your tenant - for example Authenticator Apps.

Finally, to configure the sign-in action to always challenge, go here and set the default action outcome to CHALLENGE and click save.

Authsignal settings

Step 2: Creating a Supabase project

From your Supabase dashboard, click New project.

Enter a Name for your Supabase project and enter or generate a secure Database Password, then click Create new project.

Once your project is created go to Authentication -> Settings -> Auth Providers and ensure Enable Email provider is checked and that Confirm Email is unchecked.

Supabase settings

Step 3: Building a Next.js app

Create a new Next.js project:


_10npx create-next-app --typescript supabase-authsignal-example
_10cd supabase-authsignal-example

Create a .env.local file and enter the following values:


_10NEXT_PUBLIC_SUPABASE_URL=get-from-supabase-dashboard
_10NEXT_PUBLIC_SUPABASE_ANON_KEY=get-from-supabase-dashboard
_10AUTHSIGNAL_SECRET=get-from-authsignal-dashboard
_10TEMP_TOKEN_SECRET=this-is-a-secret-value-with-at-least-32-characters

Supabase values can be found under Settings > API for your project.

Authsignal values can be found under Settings > API Keys for your tenant.

TEMP_TOKEN_SECRET is used to encrypt the temporary cookie. Set it to a random 32 character length string.

Restart your Next.js development server to read in the new values from .env.local.


_10npm run dev

Step 4: Installing dependencies

Install the Supabase client and Auth helpers for Next.js:


_10npm install @supabase/supabase-js @supabase/auth-helpers-nextjs

Install the Authsignal Node.js client:


_10npm install @authsignal/node

Finally install 2 packages to help encrypt and serialize session data in cookies:


_10npm install @hapi/iron cookie
_10npm install --save-dev @types/cookie

Step 5: Initializing the Authsignal client

Add the following code to /lib/authsignal.ts:


_11import { Authsignal } from '@authsignal/node'
_11
_11const secret = process.env.AUTHSIGNAL_SECRET
_11
_11if (!secret) {
_11  throw new Error('AUTHSIGNAL_SECRET is undefined')
_11}
_11
_11const redirectUrl = 'http://localhost:3000/api/callback'
_11
_11export const authsignal = new Authsignal({ secret, redirectUrl })

The redirectUrl here is a Next.js API route which Authsignal will redirect back to after an MFA challenge. We'll implement this below.

Step 6: Managing session data in cookies

Next we will add some helper functions for managing cookies:

setTempCookie encrypts and serializes the Supabase session data and sets it in a temporary cookie
getSessionFromTempCookie decrypts and parses this session data back from the cookie
setAuthCookie sets the Supabase auth cookies (access_token and refresh_token) and clears the temporary cookie

Add the following code to /lib/cookies.ts:


_65import Iron from '@hapi/iron'
_65import { Session } from '@supabase/supabase-js'
_65import { parse, serialize } from 'cookie'
_65import { NextApiRequest, NextApiResponse } from 'next'
_65
_65export async function setTempCookie(session: Session, res: NextApiResponse) {
_65  const token = await Iron.seal(session, TEMP_TOKEN_SECRET, Iron.defaults)
_65
_65  const cookie = serialize(TEMP_COOKIE, token, {
_65    maxAge: session.expires_in,
_65    httpOnly: true,
_65    secure: process.env.NODE_ENV === 'production',
_65    path: '/',
_65    sameSite: 'lax',
_65  })
_65
_65  res.setHeader('Set-Cookie', cookie)
_65}
_65
_65export async function getSessionFromTempCookie(req: NextApiRequest): Promise<Session | undefined> {
_65  const cookie = req.headers.cookie as string
_65
_65  const cookies = parse(cookie ?? '')
_65
_65  const tempCookie = cookies[TEMP_COOKIE]
_65
_65  if (!tempCookie) {
_65    return undefined
_65  }
_65
_65  const session = await Iron.unseal(tempCookie, TEMP_TOKEN_SECRET, Iron.defaults)
_65
_65  return session
_65}
_65
_65export function setAuthCookie(session: Session, res: NextApiResponse) {
_65  const { access_token, refresh_token, expires_in } = session
_65
_65  const authCookies = [
_65    { name: ACCESS_TOKEN_COOKIE, value: access_token },
_65    refresh_token ? { name: REFRESH_TOKEN_COOKIE, value: refresh_token } : undefined,
_65  ]
_65    .filter(isDefined)
_65    .map(({ name, value }) =>
_65      serialize(name, value, {
_65        maxAge: expires_in,
_65        httpOnly: true,
_65        secure: process.env.NODE_ENV === 'production',
_65        path: '/',
_65        sameSite: 'lax',
_65      })
_65    )
_65
_65  // Also clear the temp cookie
_65  const updatedCookies = [...authCookies, serialize(TEMP_COOKIE, '', { maxAge: -1, path: '/' })]
_65
_65  res.setHeader('Set-Cookie', updatedCookies)
_65}
_65
_65const isDefined = <T>(value: T | undefined): value is T => !!value
_65
_65const TEMP_TOKEN_SECRET = process.env.TEMP_TOKEN_SECRET!
_65const TEMP_COOKIE = 'as-mfa-cookie'
_65const ACCESS_TOKEN_COOKIE = 'sb-access-token'
_65const REFRESH_TOKEN_COOKIE = 'sb-refresh-token'

Step 7: Building the UI

We will add some form components for signing in and signing up as well as a basic home page.

Add the following code to /pages/sign-up.tsx:


_44import Link from 'next/link'
_44import { useRouter } from 'next/router'
_44
_44export default function SignUpPage() {
_44  const router = useRouter()
_44
_44  return (
_44    <main>
_44      <form
_44        onSubmit={async (e) => {
_44          e.preventDefault()
_44
_44          const target = e.target as typeof e.target & {
_44            email: { value: string }
_44            password: { value: string }
_44          }
_44
_44          const email = target.email.value
_44          const password = target.password.value
_44
_44          await fetch('/api/sign-up', {
_44            method: 'POST',
_44            headers: { 'Content-Type': 'application/json' },
_44            body: JSON.stringify({ email, password }),
_44          }).then((res) => res.json())
_44
_44          router.push('/')
_44        }}
_44      >
_44        <label htmlFor="email">Email</label>
_44        <input id="email" type="email" name="email" required />
_44        <label htmlFor="password">Password</label>
_44        <input id="password" type="password" name="password" required />
_44        <button type="submit">Sign up</button>
_44      </form>
_44      <div>
_44        {'Already have an account? '}
_44        <Link href="sign-in">
_44          <a>Sign in</a>
_44        </Link>
_44      </div>
_44    </main>
_44  )
_44}

Then add the following code to /pages/sign-in.tsx:


_48import Link from 'next/link'
_48import { useRouter } from 'next/router'
_48
_48export default function SignInPage() {
_48  const router = useRouter()
_48
_48  return (
_48    <main>
_48      <form
_48        onSubmit={async (e) => {
_48          e.preventDefault()
_48
_48          const target = e.target as typeof e.target & {
_48            email: { value: string }
_48            password: { value: string }
_48          }
_48
_48          const email = target.email.value
_48          const password = target.password.value
_48
_48          const { state, mfaUrl } = await fetch('/api/sign-in', {
_48            method: 'POST',
_48            headers: { 'Content-Type': 'application/json' },
_48            body: JSON.stringify({ email, password }),
_48          }).then((res) => res.json())
_48
_48          if (state === 'CHALLENGE_REQUIRED') {
_48            window.location.href = mfaUrl
_48          } else {
_48            router.push('/')
_48          }
_48        }}
_48      >
_48        <label htmlFor="email">Email</label>
_48        <input id="email" type="email" name="email" required />
_48        <label htmlFor="password">Password</label>
_48        <input id="password" type="password" name="password" required />
_48        <button type="submit">Sign in</button>
_48      </form>
_48      <div>
_48        {"Don't have an account? "}
_48        <Link href="sign-up">
_48          <a>Sign up</a>
_48        </Link>
_48      </div>
_48    </main>
_48  )
_48}

Now we will use Supabase's withPageAuth wrapper around getServerSideProps to make the home page require authentication via SSR. Replace the existing code in /pages/index.tsx with the following:


_50import { getUser, User, withPageAuth } from '@supabase/auth-helpers-nextjs'
_50import { GetServerSideProps } from 'next'
_50import { useRouter } from 'next/router'
_50import { authsignal } from '../lib/authsignal'
_50
_50interface Props {
_50  user: User
_50  isEnrolled: boolean
_50}
_50
_50export const getServerSideProps: GetServerSideProps<Props> = withPageAuth({
_50  redirectTo: '/sign-in',
_50  async getServerSideProps(ctx) {
_50    const { user } = await getUser(ctx)
_50
_50    const { isEnrolled } = await authsignal.getUser({ userId: user.id })
_50
_50    return {
_50      props: { user, isEnrolled },
_50    }
_50  },
_50})
_50
_50export default function HomePage({ user, isEnrolled }: Props) {
_50  const router = useRouter()
_50
_50  return (
_50    <main>
_50      <section>
_50        <div> Signed in as: {user?.email}</div>
_50        <button
_50          onClick={async (e) => {
_50            e.preventDefault()
_50
_50            const { mfaUrl } = await fetch('/api/mfa', {
_50              method: 'POST',
_50              headers: { 'Content-Type': 'application/json' },
_50              body: JSON.stringify({ isEnrolled }),
_50            }).then((res) => res.json())
_50
_50            window.location.href = mfaUrl
_50          }}
_50        >
_50          {isEnrolled ? 'Manage MFA settings' : 'Set up MFA'}
_50        </button>
_50        <button onClick={() => router.push('/api/sign-out')}>Sign out</button>
_50      </section>
_50    </main>
_50  )
_50}

Optional: To make things look a bit nicer, you can add the following to /styles/globals.css:


_47main {
_47  min-height: 100vh;
_47  display: flex;
_47  flex: 1;
_47  flex-direction: column;
_47  justify-content: center;
_47  align-items: center;
_47}
_47
_47section,
_47form {
_47  display: flex;
_47  flex-direction: column;
_47  min-width: 300px;
_47}
_47
_47button {
_47  cursor: pointer;
_47  font-weight: 500;
_47  line-height: 1;
_47  border-radius: 6px;
_47  border: none;
_47  background-color: #24b47e;
_47  color: #fff;
_47  padding: 0 15px;
_47  height: 40px;
_47  margin: 10px 0;
_47  transition: background-color 0.15s, color 0.15s;
_47}
_47
_47input {
_47  outline: none;
_47  font-family: inherit;
_47  font-weight: 400;
_47  background-color: #fff;
_47  border-radius: 6px;
_47  color: #1d1d1d;
_47  border: 1px solid #e8e8e8;
_47  padding: 0 15px;
_47  margin: 5px 0;
_47  height: 40px;
_47}
_47
_47a {
_47  color: #24b47e;
_47  cursor: pointer;
_47}

Step 8: Adding the API routes

Now we'll replace the existing api routes in /pages/api/ with 5 new routes:

/sign-in.ts: handles signing in with Supabase and initiating the MFA challenge with Authsignal
/sign-up.ts: handles signing up with Supabase
/sign-out.ts: clears the Supabase auth cookies and signs the user out
/mfa.ts: handles the user's attempt to set up MFA or to manage their existing MFA settings
/callback.ts: handles completing the MFA challenge with Authsignal

Add the following code to /pages/api/sign-in.ts:


_27import { supabaseClient } from '@supabase/auth-helpers-nextjs'
_27import { NextApiRequest, NextApiResponse } from 'next'
_27import { authsignal } from '../../lib/authsignal'
_27import { setAuthCookie, setTempCookie } from '../../lib/cookies'
_27
_27export default async function signIn(req: NextApiRequest, res: NextApiResponse) {
_27  const { email, password } = req.body
_27
_27  const { data, error } = await supabaseClient.auth.api.signInWithEmail(email, password)
_27
_27  if (error || !data?.user) {
_27    return res.send({ error })
_27  }
_27
_27  const { state, url: mfaUrl } = await authsignal.track({
_27    action: 'signIn',
_27    userId: data.user.id,
_27  })
_27
_27  if (state === 'CHALLENGE_REQUIRED') {
_27    await setTempCookie(data, res)
_27  } else {
_27    setAuthCookie(data, res)
_27  }
_27
_27  res.send({ state, mfaUrl })
_27}

Then to handle new sign-ups add the following to /pages/api/sign-up.ts:


_19import { supabaseClient } from '@supabase/auth-helpers-nextjs'
_19import { Session } from '@supabase/supabase-js'
_19import { NextApiRequest, NextApiResponse } from 'next'
_19import { setAuthCookie } from '../../lib/cookies'
_19
_19export default async function signUp(req: NextApiRequest, res: NextApiResponse) {
_19  const { email, password } = req.body
_19
_19  const { data, error } = await supabaseClient.auth.api.signUpWithEmail(email, password)
_19
_19  if (error || !isSession(data)) {
_19    res.send({ error })
_19  } else {
_19    setAuthCookie(data, res)
_19    res.send({ data })
_19  }
_19}
_19
_19const isSession = (data: any): data is Session => !!data?.access_token

To clear the auth cookies on sign-out add the following to /pages/api/sign-out.ts:


_10import { supabaseClient } from '@supabase/auth-helpers-nextjs'
_10import { NextApiRequest, NextApiResponse } from 'next'
_10
_10export default async function signOut(req: NextApiRequest, res: NextApiResponse) {
_10  supabaseClient.auth.api.deleteAuthCookie(req, res, { redirectTo: '/sign-in' })
_10}

To handle the user's actions to set up MFA or manage their existing MFA settings, add the following to /pages/api/mfa.ts:


_21import { getUser, withApiAuth } from '@supabase/auth-helpers-nextjs'
_21import { NextApiRequest, NextApiResponse } from 'next'
_21import { authsignal } from '../../lib/authsignal'
_21
_21export default withApiAuth(async function mfa(req: NextApiRequest, res: NextApiResponse) {
_21  if (req.method !== 'POST') {
_21    return res.status(405).send({ message: 'Only POST requests allowed' })
_21  }
_21
_21  const { user } = await getUser({ req, res })
_21
_21  const { isEnrolled } = req.body
_21
_21  const { url: mfaUrl } = await authsignal.track({
_21    action: isEnrolled ? 'manageSettings' : 'enroll',
_21    userId: user.id,
_21    redirectToSettings: isEnrolled,
_21  })
_21
_21  res.send({ mfaUrl })
_21})

Because the user should be authenticated with Supabase to set up or manage MFA, we can use Supabase's withApiAuth wrapper to protect this route.

The redirectToSettings param specifies whether the user should be redirected to the MFA page settings panel after a challenge, rather than redirecting them immediately back to the application.

Finally we need a route to handle the redirect back from Authsignal after an MFA challenge. Add the following to /pages/api/callback.ts:


_19import { NextApiRequest, NextApiResponse } from 'next'
_19import { authsignal } from '../../lib/authsignal'
_19import { getSessionFromTempCookie, setAuthCookie } from '../../lib/cookies'
_19
_19export default async function callback(req: NextApiRequest, res: NextApiResponse) {
_19  const token = req.query.token as string
_19
_19  const { success } = await authsignal.validateChallenge({ token })
_19
_19  if (success) {
_19    const session = await getSessionFromTempCookie(req)
_19
_19    if (session) {
_19      setAuthCookie(session, res)
_19    }
_19  }
_19
_19  res.redirect('/')
_19}

That's it! You should now be able to sign up a new user and set up MFA.

Then if you sign out, you'll be prompted to complete an MFA challenge when signing back in again.

Resources

To learn more about Authsignal take a look at the API Documentation.
You can customize the look and feel of the Authsignal Prebuilt MFA page here.

Overview
